How to Select a Ball Valve for Seawater Injection | Duplex Grades, PREN, Galvanic Corrosion

Select the valve as one assembly. Check the body, ball, stem, seats, springs, drain plugs, coatings and fasteners. The valve must also withstand the maximum closing differential pressure, release trapped cavity pressure, tolerate the expected particles and provide enough breakaway torque after a long period without movement.

Define the Water

Average ocean water contains about 35 parts per thousand, or 3.5%, dissolved salts.^[1] Typical seawater also contains about 19,000 mg/L of chloride.^[2] Open-ocean surface water is commonly around pH 8.1, while oxygenated surface water may contain dissolved oxygen near 8 mg/L, depending on temperature, salinity and biological activity.^[3][4]

These values explain why ordinary stainless steel may struggle in seawater, but they are not design limits. Use the actual water analysis from the project. ISO 21457 includes utility and injection systems in its material-selection scope and requires the relevant corrosion mechanisms and operating conditions to be reviewed.^[5]

Use the most severe condition that can actually occur. Normal water may be cool and deoxygenated, while startup water is aerated and shutdown water becomes warm and stagnant. Do not replace these conditions with a yearly average.

Check the Valve Location

A seawater injection system does not have one uniform service condition. The valve location changes the main risks.

• Intake valves may see aerated water, marine growth, sand, shells and chlorine.
• Filtered-water valves see fewer large particles, but oxygen and chlorine may remain.
• Deoxygenated-water valves normally see lower oxygen, but must also survive treatment failure, commissioning and air entry during shutdown.
• Pump-discharge valves usually see treated water but face higher pressure, closing load and surge.

State the real filter performance. A 10 μm filter, a 50 μm filter and a 100 μm filter do not create the same seat duty. Particle hardness also matters: a soft 50 μm deposit and a hard 50 μm mineral particle can affect the seat differently. Include the largest particle expected during filter bypass or failure.

For high-pressure duties, review the service against a duplex or super duplex trunnion ball valve. The trunnion ball valve selection guide also explains how pressure class, material and end connection work together.

Choose the Alloy

“2205” is a common family name linked to UNS S31803 and UNS S32205. State the exact UNS number, ASTM grade and product form in the purchase order. Do not rely on the name “2205” alone.

S32750 and S32760 are both super duplex grades, but their chemical limits and alloy additions differ. S32760 commonly includes copper and tungsten. Any substitution must include a review of chemistry, mechanical properties, welding, heat treatment and corrosion testing.

For more detail on body and trim options, see the guide to ball valve material selection.

Use PREN Carefully

PREN means Pitting Resistance Equivalent Number. A common formula is:

PREN = %Cr + 3.3 × %Mo + 16 × %N

PREN compares the chromium, molybdenum and nitrogen content of stainless steels. It is useful for screening alloy chemistry, but duplex performance also depends on heat treatment, phase balance, surface condition and valve crevices.^[6]

These are example calculations, not guaranteed values for every heat. Calculate PREN from the actual material certificate for each main wetted part. The body, ball and stem may come from three different heats and may therefore have three different calculated values.

PREN does not show:

• Water temperature or chlorine dose
• Crevice size and stagnant-water exposure
• Heat-treatment quality
• Harmful intermetallic phases
• Surface roughness or iron contamination
• Galvanic contact with another metal
• Particle or coating damage

A PREN of 42 does not mean that a valve is safe up to 42°C. PREN is not a temperature limit. Even a 10–20°C increase in water temperature can change localized-corrosion behavior, especially where warm water is trapped inside a seat pocket or body cavity.

Some specifications use a PREW formula for tungsten-bearing grades such as S32760. The purchase order must state the exact equation and minimum result. PREN and PREW values calculated with different formulas should not be compared directly.

Find the Likely Failure Points

The body wall is not always the first part to fail. In seawater valves, damage often starts where water is trapped or where a sealing surface is scratched.

A standard isolation ball valve should normally operate fully open or fully closed. Long-term throttling can create a high-speed jet across the ball and downstream seat. If the valve must regulate flow, use a design qualified for throttling rather than a standard isolation valve.

Select the Body and Bore

A floating ball valve can be suitable for smaller sizes and lower loads. Larger or higher-pressure seawater injection lines commonly use trunnion-mounted construction because the ball is mechanically supported and the seat load is easier to control.

A full-bore valve is normally preferred when:

• The line must be pigged.
• Solids may pass through the valve.
• Pressure loss must be kept low.
• A smooth pipe-to-valve transition is required.

Confirm the actual bore diameter against the pipe schedule. “Full bore” on a quotation does not prove that the valve bore matches the pipe internal diameter.

For example, reducing a bore from 100 mm to 80 mm cuts the flow area from about 7,854 mm² to 5,027 mm², a reduction of about 36%. At the same flow rate, average velocity rises by about 56%. The higher velocity can increase pressure loss and particle impact at the bore transition and seat area.

A reduced-bore valve may still be acceptable for clean water when the hydraulic calculation allows the pressure loss. See the comparison of full-bore and reduced-bore forged ball valves for the main design differences.

Check Cast and Forged Parts

ASTM A182/A182M covers forged or rolled alloy and stainless steel flanges, fittings, valves and valve parts.^[7] ASTM A995/A995M covers duplex stainless steel castings for valves, flanges, fittings and other pressure-containing parts.^[8]

Cast bodies make complex and large valve shapes easier to produce, but the inspection must address shrinkage, inclusions, section thickness and weld repairs. A small separately cast test coupon may cool faster than the thickest section of a large valve body and may not represent it accurately.

Forged bodies reduce casting-related defect risks, but many forged valves use multi-piece construction. The body joints, gaskets, bolting, alignment and heat-number traceability must still be checked.

Neither route is automatically better. Select it from valve size, pressure, geometry, inspection scope and the manufacturer’s qualified process. The cast-versus-forged offshore valve guide explains these differences in more detail.

Check Pressure and Torque

Use more than the normal operating pressure. Give the manufacturer:

• Design pressure and temperature
• Pump shut-in pressure
• Maximum closing differential pressure
• Reverse differential pressure
• Surge pressure
• Required opening and closing time

For example, a line may normally operate at 80 bar while the closed valve can see 120 bar during pump shut-in. An actuator sized only for 80 bar differential pressure may not open the valve under the 120 bar case.

API Specification 6D is in its 25th edition, with Addendum 3 issued in March 2025.^[9] ASME B16.34 covers pressure-temperature ratings, materials, dimensions, examination, testing and marking for new valve construction.^[10]

The body pressure class is only one limit. Seats, seals, bearings, stem strength and actuator output may set a lower operating limit.

Size the actuator for breakaway torque after a long inactive period. Include maximum differential pressure, deposits, bearing friction, seat aging, gearbox efficiency and the minimum available air or hydraulic pressure. A rarely operated isolation valve may move only a few times per year, while an operational valve may complete thousands of cycles; the same seat and actuator assumptions should not be used for both duties.

Control Cavity Pressure

Water can become trapped between two closed seats. Because liquid water is difficult to compress, even a 10–20°C temperature rise can create a serious pressure increase when the cavity has no relief path.

API 6D includes automatic cavity-relief requirements where liquid can become trapped.^[11]

The datasheet should state:

• Whether the seats are self-relieving
• The relief direction
• The expected seat-relief pressure or behavior
• Whether an external relief line is required
• How cavity relief works with the required isolation function

The body drain must also reach the real low point after installation. Rotating the valve or actuator assembly can move the drain away from the bottom of the cavity.

Understand DBB and DIB

DBB, DIB-1 and DIB-2 use different seat arrangements:

• DBB: two seats isolate pressure from the two line sides, and the body cavity can be bled or monitored.
• DIB-1: both seats are bidirectional.
• DIB-2: one seat is unidirectional and one is bidirectional.

API purchasing guidance identifies DIB-1 as two bidirectional seats and DIB-2 as one unidirectional seat plus one bidirectional seat.^[12]

A DIB valve can trap cavity pressure. The order must therefore state seat direction, pressure-test direction and the cavity-relief method. Writing only “DBB required” is not enough.

Select the Seats

PEEK is stronger than many PTFE-based materials, but it can require more seat load and operating torque. Metal seats tolerate harder particles but may allow more leakage than soft seats. Review the complete seat design, including support geometry, extrusion gap, spring load and permitted leakage.

Ask the supplier for the maximum qualified differential pressure, temperature range, cycle count and largest permitted particle. A seat material name without these limits does not prove that the valve suits the service.

Check the Ball

Identify whether the ball is:

• Solid super duplex
• Super duplex with a hard coating
• A lower-alloy substrate with a coating or overlay

A solid or seawater-resistant substrate is preferred where coating damage would expose an unsuitable base metal.

Some hard-coated valve balls use a finished coating thickness in the approximate 150–300 μm range, depending on the coating process, ball size and final grinding allowance. This is not a universal requirement. The purchase order should state the minimum acceptable thickness after final grinding, not only the thickness originally deposited.

For coated balls, specify:

• Substrate and coating materials
• Application process
• Applied and finished thickness
• Porosity and adhesion testing
• Hardness range
• Final surface roughness as an Ra value
• Coverage around bore edges
• Repair limits

Terms such as “hard coated” and “mirror polished” are not measurable acceptance requirements unless the supplier also states the coating and surface-finish values.

Control Galvanic Corrosion

Galvanic corrosion occurs when dissimilar metals are electrically connected in seawater. A small anodic area connected to a large cathodic area can suffer a high local corrosion rate.^[13]

For example, a 1 cm² exposed carbon-steel area connected to 100 cm² of super duplex creates an anode-to-cathode area ratio of 1:100. The corrosion current is concentrated on the small carbon-steel area, so local metal loss can be much faster than uniform corrosion over the full surface.

Check these combinations:

• Super duplex valve and carbon-steel pipe
• Super duplex body and lower-alloy drain plugs or fasteners
• Hard coating and exposed ball substrate
• Stainless valve and copper-nickel or titanium equipment
• Valve, flange bolting and electrical-isolation kit
• Actuator bracket and external marine fasteners

A small carbon-steel washer on a large super duplex valve creates a poor area ratio. A small coating holiday beside a large noble coating can create the same problem at the exposed substrate.

Do not automatically isolate the valve from a cathodically protected carbon-steel line. The piping and cathodic-protection engineers must decide whether electrical continuity or isolation is required.

Check Subsea Hydrogen Risk

Subsea duplex and super duplex parts exposed to cathodic protection also need a hydrogen-induced stress cracking review. DNV-RP-F112 covers duplex stainless steel components installed subsea and exposed to cathodic protection.^[14]

Review local stress, sharp changes in section, cold work, welding, material strength, coating damage and protection potential. Cathodic protection does not correct weak fabrication or excessive local stress.

Control Heat Treatment and Repairs

Duplex stainless steel needs correct heating and rapid cooling. Poor control can form harmful intermetallic phases that reduce toughness and corrosion resistance.

Review:

• Solution heat-treatment temperature and holding time
• Transfer time to quenching
• Cooling method and thickest section
• Weld heat input and interpass temperature
• Filler metal
• Repair map, repair depth and repair location
• Nondestructive examination after repair

ASTM A923 contains methods for detecting harmful intermetallic phases in the duplex grades covered by that standard. It does not detect every possible reason for poor toughness or corrosion performance.^[15]

The test sample should represent the part of the component that cooled most slowly. A small separate coupon may not represent the thickest section of a large cast body.

Local post-weld heat treatment should be used only when it is covered by an approved manufacturing procedure. It should not be treated as a routine repair step for duplex steel.

Specify Corrosion Tests

ASTM G48 covers ferric-chloride methods used to compare pitting and crevice-corrosion resistance of stainless steels and related alloys.^[16] A G48 result ranks material under the stated laboratory conditions; it does not predict the exact life of a completed valve in seawater.

A complete test requirement should state:

• The ASTM G48 method
• Test temperature and duration
• Sample location
• Surface preparation
• Crevice former, where required
• Weight-loss and visual acceptance limits
• Retest rules

Writing only “ASTM G48 passed” is not enough. A test performed at a lower temperature, on a polished separate coupon or without a crevice former may be much less demanding than the project requirement.

Coupon corrosion testing is separate from finished-valve inspection. The completed valve may also need dimensional checks, surface inspection, NDE, coating tests, pressure tests and functional tests.

Verify Materials and Documents

The material certificate should show the heat number, grade, UNS number, product form, chemistry, mechanical properties and heat treatment. Match the certificate to the actual component marking.

ASTM E1476 provides guidance for metal identification, grade verification and sorting.^[17] PMI can confirm selected alloying elements, but the result depends on the instrument. Handheld XRF does not normally measure nitrogen, while suitable OES equipment may do so. PMI does not prove correct heat treatment or the absence of harmful phases.

Critical seawater projects may require 100% PMI on the body, closure, ball, stem and seat retainers. Other projects may use batch sampling. The purchase order should state the exact parts and inspection percentage instead of using the general phrase “PMI required.”

A useful valve inspection and test plan should include hold, witness or review points for:

• Material certificates and heat-number traceability
• Heat treatment
• Repair welding
• Corrosion testing
• Final assembly
• Shell, seat and functional testing
• Final document release

See the guide to writing a valve inspection and test plan for practical hold and witness points.

Test and Preserve the Valve

Define shell testing, high- and low-pressure seat testing, test direction, permitted leakage, cavity-relief testing, DBB or DIB testing, operating torque and actuator testing. The requirements must match the actual seat design and applicable project standard.

The API 6D ball valve testing guide explains the difference between shell, seat and functional tests.

After hydrostatic testing:

• Drain the main bore and the body cavity.
• Flush with approved water when required.
• Dry the internal surfaces.
• Check that the drain and vent passages are open.
• Apply the specified preservation method.
• Protect the valve ends during storage.

A valve can pass its pressure test and still corrode before installation if chloride-bearing water remains behind the seats. The project should state the maximum chloride level in test water, permitted contact time and drying deadline.

Plan Shutdown and Maintenance

A shutdown plan may combine freshwater flushing, draining, drying, circulation or chemical preservation. The body cavity must be treated separately from the main line because water can stay behind the seats.

During operation, record:

• Breakaway torque
• Internal and external leakage
• Filter failures
• Chlorine upsets
• Shutdown duration
• Blocked drains or vents

Rising torque can point to deposits, bearing corrosion or seat damage. Internal leakage can come from particles, seat cuts, ball pitting or actuator travel error. The guide to ball valve leakage diagnosis explains how to separate stem leakage from seat leakage.

Check the Supplier Quote

Request clarification when a quotation:

• States “super duplex” without a UNS number.
• Provides a certificate only for the body.
• Uses a catalogue PREN instead of the actual heat chemistry.
• States “ASTM G48 passed” without method, temperature or sample location.
• Lists a coated ball without naming the substrate.
• Lists PEEK seats without maximum differential pressure or torque data.
• States DBB without showing seat direction.
• Shows a drain without confirming the installed low point.
• Uses “equivalent material” without a written engineering comparison.

A lower quote is not technically equal if it omits heat-treatment records, corrosion testing, full wetted-part traceability or a suitable actuator margin.

Conclusion

Start with the treated-water data, not the word “seawater.” Typical seawater contains about 3.5% salts and 19,000 mg/L chloride, but temperature, oxygen, chlorine, solids and stagnant periods often decide the real risk. A representative 2205 heat has a PREN near 35, while S32750 is often above 40. For raw, aerated or chlorinated injection water, S32750 or S32760 is usually a stronger starting point. Check every wetted part, seat direction, cavity relief, ball substrate and galvanic connection. Require traceable materials, representative A923 or G48 testing, pressure testing and a shutdown procedure that removes water trapped behind the seats.
